ACRYLONITRILE BUTADIENE STYRENE (ABS)

ABS Home

About ABS Material

Acrylonitrile Butadiene Styrene, or ABS, is a widely used CNC plastic, which meets the needs of many industries because of its material properties and accessible cost. ABS is one of the best machinable plastics with a low raw material cost. Both of these factors have led to the use of the material for many prototyping applications, as well as certain end-use applications.

Materials

Quick Overview

ProcessesLead TimeColorTolerancePriceApplications
CNC MachiningAs fast as 3 daysWhite & available in all major colors.With drawing: as low as +/- 0.005 mm No drawing: ISO 2768 mediumQty & Precision dependentImpact-resistant applications, production-like parts (pre-injection molding)
3D Printing2-4 Days based on sizeWhite & available in all major colors.FDM - 150 µm
SLA - 40 µm
Lowest in marketStrength & complex geometries
Injection Molding20-30 DaysWhite & available in all major colors.As low as +/- 0.030 mmQty & Precision dependentHigh strength, Good surface finish.
Materials

Design Recommendations

Services NameMax SizeMin SizeMin ThicknessUndercutsRadii Depth
For CNC MachiningMax Part Size: 600 mmMin End Mill Size: 0.8 mmMin Wall Thickness: 0.5 mmUndercuts: Square profile, full radius, dovetail profilesRadii: Depth: Depth must not exceed 12x drill bit diameter. For end mills, depth must not exceed 10x tool diameter.
For 3D PrintingMax Part Size: 500x500x500 mmMin Hole size : 1 mmMin Wall Thickness: 1 mmMin Feature Size : 3 mmRecommended fillet & Chamfer angles : > 45 Deg
For MoldingMax Part Size: 500x500x500 mmMin Hole size : 0.5 mmMin Wall Thickness: 0.5 mmRibs should be 40-60% the thickness of outer walls and should still maintain draftMinimum draft angle of 0.5°, or up to 5°, for faces with medium textures
FAQs

Frequently Asked Questions

ABS has a strong resistance to corrosive chemicals and/or physical impacts. It is very easy to machine and has a low melting temperature making it particularly simple to use in injection molding manufacturing processes or 3D printing on an FDM machine. ABS is also relatively inexpensive (prices, currently around $1.50 per pound, typically fall somewhere between those of Polypropylene  (“PP”) and Polycarbonate (“PC”). ABS plastic is not typically used in high heat situations due to its low melting point.  These characteristics lead to ABS being used in a large number of applications across a wide range of industries.



There are few factors when to choose VC or FDM.

  • When quantity is greater than 150 units.
  • When we need good strength & surface finish than FDM

For complex geometries FDM is cheaper.

For simple geometries like rods, sheCNC machining is cheaper.
